VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
3.2.

Environment Configuration

Information
The Gateway requires various configurations of parameters according to the
application. This section provides important information for using the Gateway
and the user is highly advised to follow the following procedures before
configuring the Gateway.
Clarify the network address according to the IP with the network
Environment configuration is required only once at initial installation. But when
the network components have changed, settings must be reconfigured. At
completion of configuration, always save the settings to prevent loss of data
when switching the power on/off.
In order to log in at an unconfigured Gateway, the user must use a set
username and password. The user access authority for VoiceFinder 1100 is
divided into 4 levels : admin, high, normal, low. All users, other then Admin is
prompted "1router>" at log-in.
The user must log-in at admin level for Gateway configuration. Factory settings
for admin level log-in uses "root" for username and "router" for password. The
user is prompted with "1Gateway#" for Admin level log-in and is allowed to
configure the equipment.
VoiceFinder 1100 configuration is divided into two parts : Global Configuration,
AddPac Technology Co.,Ltd.
Determine which routing protocol to use. (e.g. Static, Default etc.) In doing
so, discussion with the administrator of the connecting network is required.
Determine the protocol to use with each LAN 1(WAN) port. (e.g. PPPoE,
Ethernet etc.)
When the conditions above are determined, thoroughly understand the
related commands.
diagram.
42
- -
