VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
interface-name
5.7.2.13.2. Default Value
The default interface is Ethernet 0 .0.
5.7.2.13.3. Command Mode
Global Configuration Mode
5.7.2.13.4. Usage Guideline
With this command, users can designate the VoIP service in a certain interface.
VoIP service is provided using the IP address stored in the VoIP interface.
If no IP address is designated in the corresponding VoIP interface, VoIP-related
setup or search is impossible.
5.7.2.13.5. Examples
The following example shows how to designate the VoIP service in the Ethernet
1.0 interface.
configure
VoIP-interface ethernet 1 0
The following example shows how to designate the VoIP service in the serial 0
interface.
configure
VoIP-interface serial 0
AddPac Technology Co.,Ltd.
Designates the interface installed in the router.
Interfaces include Ethernet 0.0, Ethernet 1.0, Serial 0
and so on.
214
- -
