VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
VoIP Peers :
VoIP peer 200
dest-pattern = 2..
session-target = 20.20.20.1
codec = default
codecClass = default
dtmfRelay = h245-alphanumeric
vad = yes
translation-outgoing called-number = -1
translation-outgoing calling-number = -1
description =
administrative status = up
Gateway(config)# voice service VoIP
Gateway(config-vservice-VoIP)# no security permit-FXO
% default is permit-FXO
call scenario)
1) call Phone B to Phone D
- Hang up Phone A
- Press dial No. 100 of Phone B FXO voice port phone number.
- Press dial No. 800 of PBX machine internal phone number.
Speak over the telephone.
-
- Finish speaking out.
2) call Phone C to Phone D
- Hang up Phone C
- Press dial No. 100 of Phone C FXO voice port phone number.
- Confirm silence sound
- Finishing
설정 2) User Class Configuration.
Password check for every call under VoIP gateway A FXO voice port
Configuration)
Configuration
Gateway(config)# show dial-peer voice
POTS Peers :
Pots peer 100
dest-pattern = 100
port = 1/0 (0)
prefix =
register E.164 = yes
administrative status = up
VoIP Peers :
VoIP peer 200
dest-pattern = 2..
session-target = 20.20.20.1
codec = default
codecClass = default
