VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
5.3.2.2.

POTS Peer Configuration

Set the POTS peer as follows:
Decide the dial peer tag value.
Decide the destination pattern.
Decide the port.
In most of the cases, other values than these shall be default values.
Step
1 Router# configure
2 Router(config)# dial-peer voice
3 Router(config-dial-peer)#
destination-pattern
4 Router(config-dial-peer)# port
5 Router(config-dial-peer)# prefix
6 Router(config-dial-peer)# exit
AddPac Technology Co.,Ltd.
Command
tag
pots
string
[T]
location
string
Description
Enters into the configuration mode.
Enters into the POTS configuration
mode of the dial-peer configuration.
The tag is the only identifier of the
dial-peer of this system, and tag values
range from 0 to 65535.
The POTS means
service configuration of the FXS and
the FXO ports.
Enters the telephone number of the
corresponding dial peer.
The string means
number, and string values include 0 ~
9, (#), (*) and the wildcard (.)
The period (.) means the wildcard.
Users can selectively enter (T) after the
telephone number, and if a user enters
(T) the system will collect dial digits till
the end-of-dialing key (default #) or till
the interdigit timer finishes.
Maps the corresponding POTS with the
port that the location indicates.
The location is indicated
slot-number or the port-number.
(Selectively used.)
When the corresponding
selected as the termination side, the
string is automatically dialed-out.
String values include 0 ~ 9, (#), (*) and
(,).
When there is (,) the corresponding
digit stops dialing-out for one second.
Terminates the dial peer configuration
mode.
communication
the telephone
by the
POTS is
152
- -
