VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
access-group <access-list-number> [in/out]
As an interface command, applies the access-list to the incoming packet
or the outgoing packet of the corresponding interface.
Extended IP Access-List: To check access conditions, the extend IP
access-list uses source IP address, destination IP address, protocol ID,
application port number and establishment status.
<source
[port-number][established]
1. Creates Access-list.
2. Option explanation
AddPac Technology Co.,Ltd.
access-list <access-list-number>
wildcard>
1) access-list-number : Extended Access-List (Number in range of
30~59)
2) protocol : protocol ID Number 또는 protocol name (Ex: TCP, ICMP,
UDP IP and so on)
3) source : Source Network Address,
4) Source-wildcard : Source Address의 Inverse Mask
5) Destination : Destination Network Address
6) destination-wildcard : Destination Address의 Inverse Mask
7) operator : operator for Port #
eq : equal
gt : greater then
lt : less then
neq : not equal
8) port-number: As application port number, well known port # is as
follows:
chargen : Character generator (19)
daytime : Daytime (13)
discard : Discard (9)
domain : Domain Name Service (53)
echo : Echo (7)
finger : Finger (79)
ftp : File Transfer Protocol (21)
{deny/permit}<protocol>
<destination> <destination-wildcard>
<source>
[operator]
80
- -
