VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
[Example] Added Commands During CHAP Configuration (Server)
This is when the AP200 Gateway functions as a PPP authentication server in the
server side.
router (config)# user addpac password router1 normal
the user name (addpac) and the password (router1) with the normal
priority in the server.
router
interface configuration mode.
router (config-ether0.0)# encapsulation pppoe
mode.
router (config- ether0.0)# ppp authentication CHAP
PPP authentication mode as CHAP for the ethernet0.0 interface.
router (config- ether0.0)# ip address 132.12.1.1 255.255.255.0
☞ Sets the IP address as "130.1.1.1" and the subnet mask as "24Bit."
router (config-s ether0.0)# ppp peer default-ip address
132.12.1.2
ID from this Gateway, this command sets the IP address as the default
address "130.1.1.2."
router (config- ether0.0)# ppp timeout 100
negotiation timeout value as 100 seconds.
router (config- ether0.0)# end
menu.
router # debug ppp packet
router # undebug ppp packet
AddPac Technology Co.,Ltd.
(config)#interface
☞ When the other Gateway receives the ethernet interface
Ethernet0 LCP: TIMEOUT
Ethernet0 LCP: O CONFREQ id=1
Ethernet0 BCP: TIMEOUT
Ethernet0 BCP: O CONFREQ id=1
Ethernet0 LCP: TIMEOUT
Ethernet0 LCP: O CONFREQ id=1
Ethernet0 BCP: TIMEOUT
Ethernet0 BCP: O CONFREQ id=1
☞
erhernet0.0
☞ Sets PPP connection
☞ Exists from the configuration
☞ Stops PPP packet debugging.
☞ Registers
Enters into the
☞ Sets the PPP
☞ Sets the
