VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
4.
5.
show route
Check the routes in the routing table.
show static
Check the static route that has been set.
[Example] Static Routing Configuration and Usage
router# config
router(config)#
router(config)# ip routing
router(config)# router static
router(config)# route 130.2.0.0 255.255.0.0 131.20.1.1
packet, whose destination address is 130.2.0.0/24bit, go to address
131.20.1.1.
router(config)# route 0.0.0.0 0.0.0.0 132.20.1.1
packets, whose address is not listed in routing table, go to address
132.20.1.1. (Candidate Default; Setting of Default route)
router(config)# exit
router(config)# show route
Destination Network-Mask
--------------------------------------------------------------------
130.1.1.0
130.2.0.0
0.0.0.0
router(config)# show static
Destination Network-Mask Gateway
--------------------------------------------------------------------
AddPac Technology Co.,Ltd.
The user can designate an interface port of the Gateway instead of
the "next-hop-address."
To drop a packet that is headed for a certain destination, use the static
route that uses a null interface.
☞ Configuration is possible in this mode.
Gateway
255.255.255.0 130.1.1.1
255.255.0.0 131.20.1.1
0.0.0.0 131.20.1.1
☞Enables IP Routing.
☞ Enable static Routing Process
☞ Exit from setting mode.
☞ Shows routing table.
Cost Interface TTL Protocol
1 serial0
1 serial0
1 serial0
☞ Shows routing table setted as static.
Cost Interface TTL Protocol
☞ Set
☞ Set all
0 DIRECT
0 STATIC
0 STATIC
