VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
5.7.3.7.5. Example
Following example shows the –10 decibel gain addition to current level in the
receive port 4 of gateway.
port 4
low-dtmf-gain -10
5.7.3.8.

output gain

To configure a specific output gain value, use the output gain voice-port
configuration command. Use the no form of this command to disable the
selected output gain value.
output gain value
no output gain value
5.7.3.8.1. Syntax
Keyword / Argument
value
5.7.3.8.2. Default Value
0
5.7.3.8.3. Command Mode
Voice-port configuration Mode
5.7.3.8.4. Usage Guideline
A system-wide loss plan must be implemented using both input gain and output
gain commands. Other equipment (including PBXs) in the system must be
taken into account when creating a loss plan.
AddPac Technology Co.,Ltd.
Description
The amount of gain in decibels at the transmit side
of the interface.
Acceptable value is any integer from -31 to 31.
The default value for FXO, FXS, and E&M ports is 0..
224
- -
