4.5.2. PPPoE Configuration

Information
Point to Point Protocol (PPP) is one of standard protocol to send data through
the WAN link.
synchronous WAN (serial) line but also in the asynchronous WAN (dial up line,)
PPP can be used. Since PPP is a standard rules, it guarantees interoperability
among different manufacturers' devices.
Nowadays PPP extended to not only Serial Line but also Ethernet and ATM
Lines.
PPPoE(PPP over Ethernet) means PPP Protocol in the Ethernet Line.
PPP consists of two kinds of protocol as follows:
If a PPP encapsulation option is given to the VoiceFinder AP200 Gateway, PPP
operation is possible.
Challenge Handshake Authentication Protocol (CHAP,) the authentication
option that uses Password Authentication Protocol (PAP,) and the magic
number configuration option.
configuration option. However, software sends the authentication option only
when the authentication option is set.
AddPac Technology Co.,Ltd.
RFC1661 describes PPP specifications.
Link Control Protocol (LCP): LCP decides the encapsulation format, limits
the packet size, performs authentication in the link, decides normal
operation time and breakdown time, detects loop-back link faults and
other faults, and automatically terminates the link.
Network Control Protocol (NCP): NCP communicates with various higher
layer (network layer) protocol.
Current software installed in the Gateway supports
Software always sends the magic number
Not only in the
