CHAPTER 21 CAN CONTROLLER

21.12 Setting the CAN Direct Mode Register

To operate CAN normally, this register must be set correctly.
CAN Direct Mode Register (CDMR) (Only MB90V340)
Figure 21.12-1 Configuration of the CAN Direct Mode Register (CDMR) (Only MB90V340)
Address:
CAN0: 00796E
R/W : Readable and writable
X
: Undefined value
- : Undefined
Table 21.12-1 Function of CAN Direct Mode Register (CDMR)
Bit Name
bit 7 to 1 Undefined bits
bit 0 DIRECT
Note:
MB90360 does not have the clock modulation function.
So, at using CAN controller, the DIRECT bit of the register must be set "1".
502
7 6 5 4
H
- - - -
- - - -
If the clock modulation is set (initial state), the bit should be set "0".
If the clock modulation is not set, the bit should be set "1".
3 2 1 0
CDMR
- -
- DIRECT
Initial value
X X X X X X X 0
- - -
R/W
Function
-
B
