Fujitsu F2MCTM-16LX Hardware Manual page 31

Table 1.5-1 Pin Description (2/3)
Pin number Pin name
26 C
27 X0
28 X1
29 to 32 P24 to P27
IN0 to IN3
33, 34 P22 to P23
PPGF(E),
PPGD(C)
35, 36 P20, P21
37 P85
SIN1
38 P87
SCK1
39 P86
SOT1
40 P43
TX1
41 P42
RX1
INT9R
42 P83
SOT0
TOT2
43 P84
SCK0
INT15R
44 P82
SIN0
INT14R
TIN2
Circuit type
I Capacity pin for stabilizing power supply.
It should be connected to higher than or equal to 0.1 µF ceramic
capacitor.
A Oscillation input pin
A Oscillation output pin
G General-purpose I/O port
The register can be set to select whether to use pull-up register.
This function is enabled in single-chip mode.
Event input pin for input capture 0 to 3.
J General-purpose I/O port
The pull-up resistor ON/OFF can be set by setting the register.
This function becomes valid at shingle-chip mode.
High current output port
Output pin for PPG
J General-purpose I/O port
The pull-up resistor ON/OFF can be set by setting the register.
This function becomes valid at shingle-chip mode.
High current output port
K General-purpose I/O port
Serial data input pin for UART1
F General-purpose I/O port
Clock I/O pin for UART1
F General-purpose I/O port
Serial data output pin for UART1
F General-purpose I/O port
TX output pin for CAN1 interface
F General-purpose I/O port
RX input pin for CAN1 interface
External interrupt request input pin for INT9R (sub)
F General-purpose I/O port
Serial data output pin for UART0
Output pin for reload timer 2
F General-purpose I/O port
Clock I/O pin for UART0
External interrupt request input pin for INT15R
K General-purpose I/O port
Serial data input pin for UART0
External interrupt request input pin for INT14R
Event input pin for reload timer 2
CHAPTER 1 OVERVIEW
Functional description
15
