CHAPTER 10 I/O PORTS
10.2.5

Input Level Select Register

The input level select register allows to switch from Automotive Hysteresis input levels
to CMOS Hysteresis input levels.
Input Level Select Register (ILSR)
The input level select register ILSR is located on addresses 0E
Address
ILSR1 : 00000F
ILSR0 : 00000E
Initial value:
R/W : Read/Write
−
: Unused
X : Undefined
bit 2, bit 4 to bit6 and bit8:IL2, IL4 to IL6, IL8
These bits set the input level of the corresponding port. IL2, IL4 to IL6, IL8 correspond to the port 2,
port 4 to port 6, port 8, respectively. Setting these bits to "0" selects the Automotive input level. Setting
these bits to "1" selects the CMOS hysteresis input level. The initial value of these bits depends on the
mode pin setting:
• For the flash memory mode, the initial value is "1" (TTL).
• For all other modes, the initial value is "0" (Automotive).
bit 0, bit 1, bit 3, bit 7 and bit 9 to bit 15: undefined
Reading from these bits is undefined. Writing to these bits is no effect.
Note:
The threshold of the corresponding input pin varies immediately after the setting of the input level
select register is changed.
Therefore, do not use the read value from the pin until 2 machine cycles are elapsed after the setting is
changed.
When the setting is changed, be sure to disable the corresponding resource.
176
Figure 10.2-7 Input Level Select Register (ILSR)
15 14 13 12 11
H
− − − − −
H
− − − − −
X X X X X
and 0F
H
10 9 8 7 6
− − −
IL8 IL6
− − −
R/W R/W R/W R/W
X X 0/1 X 0/1
.
H
5 4 3 2 1
− −
IL5 IL4 IL2
− −
R/W
0/1 0/1 X 0/1 X
0
−
−
X
