1.4

Pin Assignment

This section shows the pin assignments for the MB90360 series.
Pin assignment (LQFP-48)
Figure 1.4-1 shows the pin assignments of LQFP-48 type.
P66/AN6/PPGC(D)
P67/AN7/PPGE(F)
P80/ADTG/INT12R
*1: MB90F362/T, MB90362/T, MB90F367/T, MB90367/T : X0A, X1A
MB90F362S/TS, MB90362S/TS, MB90F367S/TS, MB90367S/TS : P40, P41
*2: High current port
Figure 1.4-1 Pin Assignment (LQFP-48)
AVcc 1
2
AVR
3
P60/AN0
P61/AN1 4
P62/AN2 5
P63/AN3 6
7
P64/AN4
8
P65/AN5
9
10
11
P50/AN8 12
(FPT-48P-M26)
(TOP VIEW)
TOP VIEW
CHAPTER 1 OVERVIEW
P20 *2
36
*2
35 P21
*2
34 P22/PPGD(C)
*2
33 P23/PPGF(E)
32 P24/IN0
31
P25/IN1
30
P26/IN2
29 P27/IN3
28
X1
27
X0
26 C
25 V
ss
13
