Clock Supervisor Control Register (CSVCR)

This register switches main clock/sub clock/PLL clock, and selects the oscillation
stabilization wait time and PLL clock multiplication rate.
Clock Supervisor Control Register (CSVCR)
Address
007960
H
R/W
R
Figure 6.3-1 Clock Supervisor Control Register (CSVCR)
7 6 5 4 3 2
SCKS MM SM RCE MSVE SSVE SRST
R/W
R/W R R R/W R/W
:
Read/Write
: Read only
:
Reset value
1 0
Rese- Initial value
rved
0 0 0 1 1 1 0 0
R/W R/W
bit0
Reserved bit
Reserved
Be sure to write "0" to this bit.
0
Read value is always "0".
bit1
SRST Sub-clock mode reset
0 No generating reset on subclock mode transition
1 Generating reset on subclock mode transition
bit2
SSVE Sub clock supervisor enable
0 Sub clock supervisor is disabled.
1 Sub clock supervisor is enabled.
bit3
MSVE Main clock supervisor enable
0 Main clock supervisor is disabled.
1 Main clock supervisor is enabled.
bit4
RCE CR oscillation clock enable
0 CR oscillation clock is stopped.
1 CR oscillation clock is enabled.
bit5
SM Sub clock missing
0 Missing sub-clock has not been detected.
1 Missing sub-clock has been detected.
bit6
MM Main clock missing
0 Missing main clock has not been detected.
1 Missing main clock has been detected.
bit7
SCKS Sub clock select (for "S" suffix product)
0 Not use the CR oscillation clock as sub clock
1 Use the CR oscillation clock as sub clock
