CHAPTER 16 8-/16-BIT PPG TIMER
16.3

Configuration of 8-/16-bit PPG Timer

This section explains the pins, registers and interrupt factors of the 8-/16-bit PPG timer.

Pins of 8-/16-bit PPG Timer

The pins of the 8-/16-bit PPG timer serve as general-purpose I/O ports. Table 16.3-1 indicates the pin
functions and pin settings required to use the 8-/16-bit PPG timer.
Table 16.3-1 Pins of 8-/16-bit PPG Timer
Channel
PPGC
PPGD
PPGE
PPGF
290
Pin Name Pin Function
P66 / General-purpose I/O port,
AN6 / A/D converter analog input 6/
PPGC PPG output C
P22 / General-purpose I/O port,
PPGD PPG output D
P67 / General-purpose I/O port,
AN7 / A/D converter analog input 7/
PPGE PPG output E
P23 / General-purpose I/O port,
PPGF PPG output F
Pin Setting Required for Use of 8-/16-bit
PPG Timer
• Analog input enable register :
setting to disable(ADER6:ADE6=0)
• PPG operating mode control register :
pin output enable (PPGCC:PE0=1)
• PPG operating mode control register :
pin output enable (PPGCD:PE1=1)
• Analog input enable register :
setting to disable (ADER6:ADE7=0)
• PPG operating mode control register :
pin output enable (PPGCE:PE0=1)
• PPG operating mode control register :
pin output enable (PPGCF:PE1=1)
