4.3.1 Delayed interrupt request generate/cancel register
(DIRR)
The delayed interrupt request generate/cancel register (DIRR) generates or cancels a
delayed interrupt request.

Delayed Interrupt Request Generate/cancel Register (DIRR)

Figure 4.3-2 Delayed Interrupt Request Generate/cancel Register (DIRR)
Address 15
00009F
H
−
−
: Undefined
R/W : Read/Write R/W
: Reset value
Table 4.3-1 Functions of Delayed Interrupt Request Generate/Cancel Register (DIRR)
bit8
bit9
to
bit15
14 13 12 11 10
− − − − −
Bit name
R0: This bit generates or cancels a delayed interrupt request.
Delayed interrupt When set to "0": Cancels delayed interrupt request
request generate bit When set to "1": Generates delayed interrupt request
Undefined bits Read: The value is undefined.
Write: No effect
CHAPTER 4 DELAYED INTERRUPT GENERATION MODULE
9 8 Reset value
R0 XXXXXXX0
B
−
R/W
bit8
R0 Delayed interrupt request generate bit
0 Release of delay interrupt request
1 Generation of delay interrupt request
Function
