CHAPTER 21 CAN CONTROLLER
21.3

List of Overall Control Registers

Following Table lists the register.
List of overall Control Registers
Table 21.3-1 List of overall Control Register (1 / 2)
Address
CAN1
000080
H
Message buffer valid register
000081
H
000082
H
Transmit request register
000083
H
000084
H
Transmit cancel register
000085
H
000086
H
Transmit complete register
000087
H
000088
H
Receive complete register
000089
H
00008A
Remote request receiving
H
register
00008B
H
00008C
H
Receive overrun register
00008D
H
00008E
H
Receive interrupt enable register
00008F
H
007D00
H
Control status register
007D01
H
007D02
H
Last event indicator register
007D03
H
007D04
H
Receive/transmit error counter
007D05
H
007D06
H
Bit timing register
007D07
H
007D08
H
IDE register
007D09
H
007D0A
H
Transmit RTR register
007D0B
H
446
Register Abbreviation
BVALR
TREQR
TCANR
TCR
RCR
RRTRR
ROVRR
RIER
CSR
LEIR
RTEC
BTR
IDER
TRTRR
Access
R/W 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
W 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W, R 0 0 XXX 0 0 0 0 XXXX0 X1
R/W XXXXXXXX 0 0 0 X0 0 0 0
R 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W X1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
R/W XXXXXXXX XXXXXXXX
R/W 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Initial Value
