DAI Signal Routing Unit Registers
31 30 29 28 27 26 25 24
DAI_PB08_I (27–21)
DAI Pin Buffer 8 Input
15 14 13 12
DAI_PB07_I (20–14)
DAI_PB06_I (13–7)
DAI Pin Buffer 6 Input
Figure A-56. SRU_PIN1 Register
31 30 29 28 27 26 25 24
DAI_PB12_I (27–21)
DAI Pin Buffer 12 Input
15 14 13 12
DAI_PB11_I (20–14)
DAI_PB10_I (13–7)
DAI Pin Buffer 10 Input
Figure A-57. SRU_PIN2 Register
31 30 29 28 27 26 25 24
DAI_PB16_I (27–21)
DAI Pin Buffer 16 Input
15 14 13 12
DAI_PB15_I (20–14)
DAI_PB14_I (13–7)
DAI Pin Buffer 14 Input
Figure A-58. SRU_PIN3 Register
A-94
www.BDTIC.com/ADI
23 22 21 20 19 18 17 16
11 10 9 8 7 6 5
23 22 21 20 19 18 17 16
11 10 9 8 7 6
23 22 21 20 19 18 17 16
11 10 9 8 7 6 5
ADSP-2136x SHARC Processor Hardware Reference
for the ADSP-21362/3/4/5/6 Processors
DAI_PB07_I (20–14) (con't)
DAI Pin Buffer 7 Input
4 3 2 1 0
DAI_PB05_I (6–0)
DAI Pin Buffer 5 Input
DAI_PB11_I (20–14) (con't)
DAI Pin Buffer 11 Input
5 4 3 2 1 0
DAI_PB09_I (6–0)
DAI Pin Buffer 9 Input
DAI_PB15_I (20–14) (con't)
DAI Pin Buffer 15 Input
4 3 2 1 0
DAI_PB13_I (6–0)
DAI Pin Buffer 13 Input
