VoiceFinder AP1200 VoIP Gateway Installation Guide Version 1.0

Network Interface

VoiceFinder AP1200 Gateway supports the following network interfaces.
2-port 10/100Mbps Ethernet Interface for WAN/LAN
1-port RS232C Asynchronous Serial Interface
With the above network interfaces, VoiceFinder AP1200 Gateway can establish WAN
and LAN network supporting TCP/IP network protocol. So it can easily form VoIP
network on the lease line or the broadband network of ADSL and Cable Modem. Also,
the Console port offers easy configuration of the gateway.
The next section explains the network interfaces of VoiceFinder AP1200 Gateway.
2-Port 10/100Mbps Fast Ethernet WAN/LAN Interface (RJ45)

Figure 1-7: VoiceFinder AP1200 VoIP Gateway WAN/LAN Interface

VoiceFinder AP1200 Gateway supports two (2) 10/100Mbps Fast Ethernet Interfaces
for WAN/LAN environment formation. (2* RJ45 type standard interface).
AddPac Technology Co., Ltd.
19
- -
