Omron CS1W-MCH71 MOTION CONTROL UNIT - 09-2004 Manual page 86

System Parameters
Bit
00 Axis 1
Sets whether input to Axis 1 control bit area
(x+0) and Axis 1 control data area (d+0) are
enabled or disabled.
0: Normal
1: Ignored
01 Axis 2
Sets whether input to Axis 2 control bit area
(x+1) and Axis 2 control data area (d+1) are
enabled or disabled.
0: Normal
1: Ignored
02 Axis 3
Sets whether input to Axis 3 control bit area
(x+2) and Axis 3 control data area (d+2) are
enabled or disabled.
0: Normal
1: Ignored
03 Axis 4
Sets whether input to Axis 4 control bit area
(x+3) and Axis 4 control data area (d+3) are
enabled or disabled.
0: Normal
1: Ignored
04 Axis 5
Sets whether input to Axis 5 control bit area
(x+4) and Axis 5 control data area (d+4) are
enabled or disabled.
0: Normal
1: Ignored
05 Axis 6
Sets whether input to Axis 6 control bit area
(x+5) and Axis 6 control data area (d+5) are
enabled or disabled.
0: Normal
1: Ignored
06 Axis 7
Sets whether input to Axis 7 control bit area
(x+6) and Axis 7 control data area (d+6) are
enabled or disabled.
0: Normal
1: Ignored
07 Axis 8
Sets whether input to Axis 8 control bit area
(x+7) and Axis 8 control data area (d+7) are
enabled or disabled.
0: Normal
1: Ignored
08 Axis 9
Sets whether input to Axis 9 control bit area
(x+8) and Axis 9 control data area (d+8) are
enabled or disabled.
0: Normal
1: Ignored
09 Axis 10
Sets whether input to Axis 10 control bit
area (x+9) and Axis 10 control data area
(d+9) are enabled or disabled.
0: Normal
1: Ignored
Function and explanation Bit Function and explanation
16 Axis 17
Sets whether input to Axis 17 control bit
area (x+16) and Axis 17 control data area
(d+16) are enabled or disabled.
0: Normal
1: Ignored
17 Axis 18
Sets whether input to Axis 18 control bit
area (x+17) and Axis 18 control data area
(d+17) are enabled or disabled.
0: Normal
1: Ignored
18 Axis 19
Sets whether input to Axis 19 control bit
area (x+18) and Axis 19 control data area
(d+18) are enabled or disabled.
0: Normal
1: Ignored
19 Axis 20
Sets whether input to Axis 20 control bit
area (x+19) and Axis 20 control data area
(d+19) are enabled or disabled.
0: Normal
1: Ignored
20 Axis 21
Sets whether input to Axis 21 control bit
area (x+20) and Axis 21 control data area
(d+20) are enabled or disabled.
0: Normal
1: Ignored
21 Axis 22
Sets whether input to Axis 22 control bit
area (x+21) and Axis 22 control data area
(d+21) are enabled or disabled.
0: Normal
1: Ignored
22 Axis 23
Sets whether input to Axis 23 control bit
area (x+22) and Axis 23 control data area
(d+22) are enabled or disabled.
0: Normal
1: Ignored
23 Axis 24
Sets whether input to Axis 24 control bit
area (x+23) and Axis 24 control data area
(d+23) are enabled or disabled.
0: Normal
1: Ignored
24 Axis 25
Sets whether input to Axis 25 control bit
area (x+24) and Axis 25 control data area
(d+24) are enabled or disabled.
0: Normal
1: Ignored
25 Axis 26
Sets whether input to Axis 26 control bit
area (x+25) and Axis 26 control data area
(d+25) are enabled or disabled.
0: Normal
1: Ignored
Section 4-2
63
