7.5.4.2.2

Admin | SNMP

•
Chapter 6. FRONT PANEL OPERATION
• Sect. 7.3 SNMP INTERFACE
The Administrator must use this page to set and return administration information for the
modem's SNMP feature.
SNMP
•
Simple Network Management: Use the drop-down list to select as Disabled or
Enabled.
•
Enable Authentication Trap: Use the drop-down list to select as Disable or Enable.
Trap IP 1 / 2: Assign up to two SNMP Trap IP Addresses in the form xxx.xxx.xxx.xxx.
Trap Version: Use the drop-down list to select SNMPv1 or SNMPv2.
•
Read Community String, Write Community String, SNMP Contact, SNMP Name,
SNMP Location, and Trap Community String: Create or edit these alphanumeric text
strings as follows:
•
SNMP Read Community String
SNMP Write Community String
SNMP Trap Community String
SNMP Contact
SNMP Name
SNMP Location
Ethernet-based Remote Product Management
Figure 7-7. Admin | SNMP Page
Setting Factory Default
CDM-425 Advanced Satellite Modem
public
The Read, Write, and Trap Community Strings
private can be any alphanumeric combination with a
maximum length of 4 to 15 characters.
comtech
N/A
The SNMP Contact, Name, and Location strings
N/A can be any alphanumeric combination with a
maximum length of 0 to 20 characters.
N/A
7–21
Revision 0
Typical Parameters
