Date and Time
•
Time: Enter a time using HH:MM:SS format (where HH = hour [00 to 23], MM = minutes
[00 to 59], and SS = seconds [00 to 59]).
•
Date: Enter a date using DD/MM/YY format (where DD = day [01 to 31], MM = month [01
to 12], and YY = year [00 to 99]).
Click [Enter Date/Time] once you set the desired date and time.
7.5.4.3.12

Configuration | MEO

The optional IP Packet Processor must be installed and active, with IP-ACM or
V2-ACM selected as the active operating mode, and Carrier-in-Carrier disabled for
any MEO Operational Modes to be accessible. Otherwise, this page is
nonfunctional.
CDM-425 Advanced Satellite Modems are configurable for continuous pairing as Primary and
non-Primary Modems in an Antenna Handover System when the MEO feature is enabled.
Ethernet data traffic is transmitted and received via the Primary and Non-Primary CDM-625's four
10/100 Ethernet ports. The Antenna Handover signal received from the user-provided IF/RF
switch determines which modem is the ONLINE or OFFLINE unit:
•
The ONLINE unit transmits traffic only to the WAN side while, at the same time, the
OFFLINE unit's Tx is muted.
•
Both the ONLINE and OFFLINE units receive the satellite traffic, but only the ONLINE
unit forwards traffic to the LAN side while the OFFLINE unit drops the packets.
•
Any time a unit switches from the OFFLINE to ONLINE state, the traffic destined for the
WAN is buffered, preconfigured in milliseconds (base modem → Antenna Handover
delay).
Ethernet-based Remote Product Management
Figure 7-38. Configuration | MEO Page
