9.3.3.5 Home > Modem > ACM (Adaptive Coding and Modulation)
Appendix K. ADAPTIVE CODING
Open the ACM page from the Modem submenu. Use this page as a quick reference guide for the
Minimum and Maximum Tx ModCod settings. This submenu contains the following options:
Hot
Key
A ACM Min Tx Mod Cod
B
ACM Max Tx Mod Cod
C
ACM Action on Remote Demod Unlock
D
ACM Target Eb No Margin
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
Telnet Command Line Interface (CLI) Operation
Dialog Window
CDM-425 Advanced Satellite Modem
MODULATION (ACM) OPTION
AND
Option Entry
Enter a minimum value from 0 to 11
Enter a maximum value from 0 to 11
Use the ↑↓ arrow keys to select Go To Min Tx ModCod or
Maintain Tx ModCod
Enter a value from 0.0 to 4.5 dB
9–32
Revision 0
MN-CDM-425
