1.4.8

Miscellaneous

Front Panel
Loopbacks
Fault relays
M&C Interface
M&C Software
Firmware update
Dimensions
Weight
AC consumption
AC operating voltage
DC consumption
(option)
DC operating voltage
Operating temperature
1.4.9

Approvals

"CE" as follows:
FCC
Introduction
Tactile keypad, 6 keys (up, down, left, right, ENTER, CLEAR)
Vacuum Fluorescent Display (blue) – two lines @ 40 characters/line
Internal IF loopback, RF loopback, digital loopback, and inward/outward loopback
Hardware fault, Rx and Tx Traffic Alarms, Open Network Backward Alarms
Type: Form C Contacts. Rating: Up to ±50 volts, maximum 0.5 Amp
EIA-232 and EIA-485 (addressable multidrop, 2-wire or 4-wire) or Ethernet (10/100 BaseT)
Serial comms, SNMP, Telnet, HTTP (Web Server)
FTP protocol via Ethernet port
1RU high, 14.0 inches (355.6 mm) deep
8.0 lbs (3.6 kg) maximum (All option cards and 48V BUC supply installed)
43 watts (typical)
200 watts (typical, and 48 volt BUC supply installed)
100-240 VAC Nominal – autosensing
90-264 VAC Maximum
40 watts (typical)
195 watts (typical, and 48 volt BUC supply installed)
20-60 VDC Nominal
36-60 VDC Maximum
32°-122°F (0°-50°C)
EN 55022 Class B
(Emissions)
EN 50082-1 (Immunity)
EN 60950-1 (Safety)
Federal Communications Commission Federal Code of Regulation FCC Part 15, Subpart B.
CDM-425 Advanced Satellite Modem
EN 61000-3-2
EN 61000-3-3
EN 61000-4-2
EN 61000-4-4
EN 61000-4-5
1–34
Revision 0
EN 61000-4-6
EN 61000-4-8
EN 61000-4-9
EN 61000-4-11
EN 61000-4-13
MN-CDM-425
