10.5 ODU Operations via the Telnet Command Line Interface (CLI)

Chapter 9. TELNET COMMAND LINE INTERFACE (CLI) OPERATION
The Telnet Command Line Interface (referred to hereafter as the Telnet CLI or the CLI) (Figure
10-17) is an Ethernet-based user menu system for the CDM-425 Advanced Satellite Modem
equipped with an installed and enabled optional IP Packet Processor card. The CLI facilitates
configuration, monitoring, and control of a CSAT-5060 Transceiver (ODU), installed in standalone
or 1:1 Redundancy configurations, using a user-supplied terminal emulator.
1. The CDM-425 Telnet Command Line Interface (CLI) is accessible only when
2. The CDM-425 Telnet CLI uses Telnet TCP Port 107. Be sure to specify this
3. For best results Comtech EF Data recommends PuTTY or Tera Term as the
4. The Telnet CLI's Remote Access Mode must be set to [Ethernet] in order to
Figure 10-16. Telnet Command Line Interface (CLI)Tera Term Example
ODU (Transceiver, BUC, LNB) Operation
the optional IP Packet Processor is installed and enabled.
port when configuring your terminal emulator for CLI operation.
preferred terminal emulators.
use the Telnet CLI for ODU operations.
