The modem calculates and then displays, on the top line from left to right, statistics data as
follows:
•
(22.0,22.0) First, the SNR is calculated: The minimum SNR value observed during the
measurement interval is provided first, and then the average SNR observed value
follows. The screen displays 16.0 only if the measured values are ≥16.0 dB.
•
(B) Next, the Rx ModCod that was current when the entry was logged.
o
o
•
(B) Number of Rx ModCod changes, in hex format, during the measurement interval.
•
(21.6,21.6) Finally, the RSL is calculated (note that both values are negative): The
minimum value observed in the measurement interval is provided first, and then the
average RSL observed value follows.
In V2-ACM Mode, the modem calculates and then displays, on the top line from left to right,
statistics data as follows:
Stats 116: 22.0,22.0,37,37,21.9,21,6
17/11/14 11:18:44
The modem calculates and then displays, on the top line from left to right, statistics data as
follows:
•
(22.0,22.0) First, the SNR is calculated: The minimum SNR value observed in the
measurement interval is provided first, and then the average SNR observed value
follows. The screen dislays 16.0 only if the measured values are ≥16.0 dB.
•
(37) Maximum Rx ModCod, in decimal format, during the measurement interval.
•
(37) Minimum Rx ModCod, in decimal format, during the measurement interval.
•
(22.6, 22.4) (21.6,21.6) Finally, the RSL is calculated (note that both values are
negative): The minimum value observed in the measurement interval is provided first,
and then the average RSL observed value follows.
6.2.3.5 Monitor: Rx Parameters Rx-Parameters: EbNo=11.4dB
∆F=+011.7kHz
BER=0.0E-9
When in IP-ACM or V2-ACM mode:
Rx-Parameters: SNR=11.4dB
BER=0.0E-9
Front Panel Operation
Maximum Rx ModCod, in hex format, during the measurement interval.
Minimum Rx ModCod, in hex format, during the measurement interval.
Buffer=51%
Buffer=51%
CDM-425 Advanced Satellite Modem
Clear-All: No
RxLevel=-43.5dBm
∆F=+011.7kHz
RxLevel=-43.5dBm
6–85
Revision 0
(N/Y)
MN-CDM-425
