9.3.3.12 Home > Modem > Overhead
Open the scrollable Overhead page from the Modem submenu. This page contains the following
options:
Hot
Key
A
AUPC Enable
[RO]
AUPC ACM Mode
C AUPC ACM Tx Power Max Increase
E AUPC Action On Max Power
AUPC Action On Remote Demod
F
Unlock
G EDMAC Mode
H EDMAC Address
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
Telnet Command Line Interface (CLI) Operation
Dialog Window
CDM-425 Advanced Satellite Modem
Option Entry
Use the ↑↓ arrow keys to select Disable or Enable
This read-only entry displays the AUPC ACM Mode.
Enter a value from 0 to 9 dB
Use the ↑↓ arrow keys to select No Action, Generate Tx Alarm
Max Power, or Generate Tx Alarm Minimum ModCod
Use the ↑↓ arrow keys to select Go To Nominal Power, Go To
Max Power, or Hold
Use the ↑↓ arrow keys to select Off, Master, or Slave
Enter a value from 0 to 9999
