8.5.6

Modem Information

Command
Number of
Parameter (Instruction
Arguments
& Qualifier)
Hardware N/A 4 bytes
Revision
Software N/A 5 bytes
Revision
Firmware N/A 256 bytes
Information
Serial Number N/A 9 bytes
Fractional N/A 7 bytes
CnC 90-day
Counter
Modem N/A 8 bytes
Operational
Full Year
Counter
Software N/A 38 bytes
Revision 2
Serial Remote Control
Description of Arguments
Query only.
Returns hardware revision level of both main circuit cards in the form of xx.y, where:
xx indicates the main (bottom) card;
y indicates the top (modem) card.
Query only.
Returns the installed firmware version number, in the form of x.x.x, where:
EXAMPLE: <0/SWR? >0/SWR=2.0.2
Query only.
Returns the installed firmware information.
NOTE: <0/FRW?B requests boot code information.
EXAMPLE: FRW=Boot:FW-0021098-,1.1.1,01/03/17
Otherwise, FRW returns firmware information for Image 1 or 2:
EXAMPLE:
<0/FRW2
>0000/FRW=2:
FW-0021099- ,1.1.1,11/09/17
FW-0021100- ,1.1.1,07/09/17
FW/12867AG ,2.3.3,28/07/14
FW/12868L ,2.3.1,15/04/13
FW-0021102- ,1.1.1,08/09/17
FW-0021101- ,1.1.3,05/09/17
FW-0000516- ,1.1.1,19/01/11
Query only.
Returns the modem 9-digit serial number.
EXAMPLE: <0/SNO? >0/SNO=176500143
Query Only.
Returns the number of seconds that Fractional CnC license has been used in the 1-year period since the
last reset of the CnC counter to 0.
EXAMPLE: <0/FCC? >0/FCC=0000455 (indicating 455 seconds)
Query Only.
Returns the number of seconds that the unit has been powered on since the last reset of the CnC
counter.
The counter resets to 0 when it reaches 31536000 seconds (seconds in 365 days).
EXAMPLE: <0/FCF? >0/FCF=00001342 (indicating 1342 seconds)
Query only.
Returns the installed firmware version numbers in the Boot, Image 1, and Image 2 slots.
EXAMPLE: <0/SW2? >0/SW2=Boot:2.1.1 Bulk1*:2.1.2 Bulk2 :2.1.1
The current active image is indicated with an asterisk.
8–48
CDM-425 Advanced Satellite Modem
Revision 0
Query
Response to
(Instruction Response to Query
Command
& Qualifier)
N/A HRV? HRV=xx.y
(see Description of
Arguments)
N/A SWR? SWR=x.x.x
(see description
of arguments)
N/A FRW?B FRW=xxx...xxx
FRW?1 (see Description of
FRW?2 Arguments)
N/A SNO? SNO=xxxxxxxxx
(see Description of
Arguments)
N/A FCC? FCC=xxxxxxx
(see Description of
Arguments)
N/A FCF? FCF=xxxxxxxx
(see Description of
Arguments)
N/A SW2? SW2=x
(see Description
of Arguments)
MN-CDM-425
