Comtech EF Data CDM-425 Installation And Operation Manual page 262

Configuration | LAN | ARP
This nested page is accessible only to Admin users and when you install and
enable the optional IP Packet Processor card. See Sect. 7.5.3.1 for complete
details about using conditional access pages.
ARP (Address Resolution Protocol) is a technique by which the HTTP Interface in Router Mode
on a given network answers the ARP queries for a network address that is not on this network,
but is reachable via the IP Packet Processor Interface.
Use this page to configure the modem's ARP parameters.
ARP Table (Edit)
This section displays all current Static and Dynamic ARP entries, and allows to user to directly
edit the current Static ARP entries, when more than one ARP entry exists. Note the following:
Column
Index
IP
MAC
Type
Click [Submit Changes] to save.
Ethernet-based Remote Product Management
Figure 7-17. Configuration | LAN | ARP Page
This is the internal table index that is automatically assigned and cannot be edited.
IP Address, in the format XXX.XXX.XXX.XXX.
MAC Address, in the format YY:YY:YY:YY:YY:YY.
Type is identifiable as Static or Dynamic (cannot be edited).
CDM-425 Advanced Satellite Modem
Description
7–38
Revision 0
MN-CDM-425
