10.5.1.2.1.4 Home > Outdoor Unit (ODU) > CSAT-5060 > LNA Settings
Open the LNA Settings page from the nested CSAT-5060 submenu. This page contains the
following options:
Hot
Key
A
Unit LNA Current Window
B
Unit LNA Current Window
C
Unit LNA Fault Logic
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the nested CSAT-
5060 submenu.
ODU (Transceiver, BUC, LNB) Operation
Dialog Window
CDM-425 Advanced Satellite Modem
Option Entry
Enter a value as follows:
Range 1 – 20 to 50
Range 2 – 99 to 99
Use the ↑↓ arrow keys to select Disabled, Enabled, or Enabled
When Online
Use the ↑↓ arrow keys to select No Summary or Summary
