9.3.4.5.1 Home > Network > Routes > Route Table
Open the Route Table from the nested Routes submenu. Use the ↑↓ arrow keys to scroll through
the available entries. You may also select a header (e.g., <Index 1>) and press [ENTER] to view,
in a standalone window, a specific Route Index page as shown in this example:
Each available Index # page contains the following options:
Hot
Key
A
Route Description
B Route Destination Address/Mask
C
Route Interface
D
Route LAN Next Hop Address
E
Route Header Compression
F
Route Payload Compression
G
Route Encryption
H
Route Encryption Key
Typical for any accessed Index # page, press a hot key to open a dialog window. Otherwise,
press [ESC] twice to return to the Network submenu.
Telnet Command Line Interface (CLI) Operation
Dialog Window
CDM-425 Advanced Satellite Modem
Option Entry
Enter a description here
Enter an IP Address/Range in the form XXX.XXX.XXX.XXX/XX
Use the ↑↓ arrow keys to select LAN or WAN
Enter an IP Address in the form XXX.XXX.XXX.XXX
Typical for each entry – Use the ↑↓ arrow keys to select Disable
or Enable
Use the ↑↓ arrow keys to select Key 1 through Key 8, or
Random
