Command
Length of
Parameter
(Instruction
Argument
& Qualifier)
Rx Sub-Mux
RMR=
2 bytes,
Ratio
numeric
Rx Spectrum
RSI=
1 byte,
Invert
0 or 1
Rx Descrambler
RDS=
1 byte,
0 or 1
Rx Demod
RSW=
3 bytes
Acquisition
Sweep Width
Rx Clock
RCK=
1 byte,
Source
0 thru 3
Rx Clock Invert
RCI=
1 byte,
0 or 1
Serial Remote Control
Description of Arguments
Command or Query.
Sets or returns Rx Sub-Mux Ratio (IP/Synchronous Interface) in the form xx, where:
00=1/9
09=3/7
01=1/8
10=1/2
02=1/7
11=3/5
03=1/6
12=2/3
04=1/5
13=3/4
05=1/4
14=4/5
06=2/7
15=1/1
07=1/3
16=5/4
08=2/5
17=4/3
EXAMPLE: <0/RMR=01 (Selects ratio 1/8)
Command or Query.
Sets or returns Rx Spectrum Invert in the form x, where:
0=Normal
1=Rx Spectrum Invert
EXAMPLE: <0/RSI=0 (selects Normal)
Command or Query.
Sets or returns Rx Descrambler state in the form x, where:
0=Off
1=Normal
2=IESS-315
EXAMPLE: <0/RDS=1 (Scrambler On)
Command or Query.
Sets or returns Rx ± Acquisition Sweep Range of demodulator, in kHz.
Available range depends on the symbol rate:
18ksps to 64ksps:
±1 to the symbol rate (ksps)/2
64ksps to 389ksps:
±1 to the symbol rate (ksps)/2
389ksps to 3000ksps:
±1 to the symbol rate (ksps)/2
>3000ksps:
±1 to the symbol rate (ksps)/2
EXAMPLE: <0/RSW=009 (selects ± 9 kHz)
Command or Query.
Sets or returns Rx Clock Source in the form x, where:
0=Rx Satellite
1=Tx-Terrestrial
2=Internal(SCT)
3=INSERT (command valid only when Rx framing is Insert or D&I++ and interface is G.703 or set for
D&I loop)
EXAMPLE: <0/RCK=1 (selects Tx-Terrestrial)
Command or Query.
Sets or returns Invert Receive Clock, in the form x, where:
0=Normal
1=Inverted
18=3/2
27=6/1
19=5/3
28=7/1
20=2/1
29=8/1
21=7/3
30=9/1
22=5/2
31=1/59
23=3/1
32=1/39
24=7/2
33=1/19
25=4/1
26=5/1
8–22
CDM-425 Advanced Satellite Modem
Revision 0
Query
Response to
(Instruction
Response to Query
Command
& Qualifier)
RMR?
RMR?
RMR=xx
RMR=
(see Description of
RMR*
Arguments)
RMR#
RSI=
RSI?
RSI=x
RSI?
(see Description of
RSI*
Arguments)
RSI#
RDS=
RDS?
RDS=x
RDS?
(see Description of
RDS*
Arguments)
RDS#
RSW=
RSW?
RSW=xxx
RSW?
(see Description of
RSW*
Arguments)
RSW#
RCK=
RCK?
RCK=x
RCK?
(see Description of
RCK*
Arguments)
RCK#
RCI=
RCI?
RCI=x
RCI?
(see Description of
RCI*
Arguments)
RCI#
MN-CDM-425
