9.3.4.3.1 Home > Network > LAN ARP > Arp Table > Arp Entry #
Open the ARP Table from the nested ARP submenu. Use the ↑↓ arrow keys to scroll through the
available entries. You may also select a header (e.g., <ARP Entry 1>) and press [ENTER] to
view, in a standalone window, a specific ARP Entry page as shown in this example:
This window displays the ARP Type for the specific ARP Entry #. It contains the following
options:
Hot
Key
A
ARP IP Address
B ARP MAC Address
Press a hot key to open a dialog window. Otherwise, press [ESC] twice to return to the Network
submenu.
Telnet Command Line Interface (CLI) Operation
Dialog Window
CDM-425 Advanced Satellite Modem
Option Entry
Enter an IP Address in the form XXX.XXX.XXX.XXX
Enter a MAC Address in the form of this example:
90:e2:ba:2b:a6:bb
9–50
Revision 0
MN-CDM-425
