8.5.5
Bulk Configuration Strings
NOTE: In order to completely get/set the configuration of the modem, the following commands must be queried/set:
•
MGC
•
OGC (L-Band Only)
•
Drop and Insert (specified in MGC):
DNI (Open Network Drop and Insert );
o
DIC (Closed Network DNI++ Drop and Insert);
o
QDI (Quad Drop and Insert), one for each active port up to a maximum of four.
o
Command
Number of
Parameter
(Instruction
Arguments
& Qualifier)
Global
MGC=
224 bytes,
Configuration
numerical entries,
fixed values, and
delimiters
Serial Remote Control
Description of Arguments
Command or Query.
Global Configuration of CDM-425, in the form shown in the Response to Query column (to right)
where:
FFFF.FFFF=Tx Frequency*
DDDDD.DDD=TX Data Rate
G=Tx FEC Type
X=1 Spare Byte
R=Tx FEC Rate
M=Tx Modulation Type
V=Tx Spectrum Inversion
S=Tx Scrambler State
PP.P Tx Power Level
B=AUPC Enable
aaa.aa=AUPC Parameter Setup
C=Tx Clock Source
X=Tx Carrier State
I=Tx Interface Type
K=Tx Ternary Code
N=Tx Framing Mode
Z=Tx Clock Invert*
ffff.ffff=Rx Frequency*
ddddd.ddd=Rx Data Rate
g=Rx FEC Type
x=1 Spare Byte
r=Rx FEC Rate
m=Rx Modulation Type
v=Rx Spectrum Inversion
s=Rx Scrambler State
www=Rx Sweep Width*
c=Rx Clock Source
ll.l=Eb/No Alarm Point
bbbbb=Rx Buffer Size
same as TFQ
same as TDR
same as TFT
same as TCR
same as TMD
same as TSI
same as TSC
same as TPL
same as AUP
same as APP
same as TCK
same as TXO
same as TIT
same as TTC
same as TFM
same as TCI
same as RFQ
same as RDR
same as RFT
same as RCR
same as RMD
same as RSI
same as RDS
same as RSW
same as RCK
same as EBA
same as RBS
8–42
CDM-425 Advanced Satellite Modem
Revision 0
Response
Query
to
(Instruction &
Response to Query
Command
Qualifier)
MGC=
MGC?
MGC=FFFF.FFFFDDD
MGC?
MGC?n (where
DD.DDDGXRMVSPP.P
MGC*
n=0 thru 9.
Baaa.aaCXIKNZffff.ffffd
MGC#
Returns the
dddd.dddgxrmvswwwcll.
MGC portion of
lbbbbbiknzOEEEETeee
1 of 10 stored
eeeeeeeeeeWALQUxxx
configurations)
xxxxxxxxxxxxxabxxefAB
CCDDmMATrrrrr.rrrssss
s.sssxgkpxxxxttuuu.uuu.
uuu.uuu.uuvvv.vvv.vvv.v
vvwGHIJKwAAABBBC
CCeeEFGGGH
MN-CDM-425
