6.2.4.10 Info: Remote

Remote-Control= Local
Interface= RS-232
This screen displays if the unit is in Local, Remote or Ethernet (IP) mode; the electrical interface
type selected; the unit's address; and the active baud rate.

6.2.4.11 Info: Alarm-Mask

Alarms Masked: TxAIS
CnC Buffer AGC RxAIS
This screen displays only the alarm(s) that are currently masked. This example shows all
available parameters as present and operational. For any alarm that is not masked, a blank
space assumes that parameter's designated screen position.

6.2.4.12 Info: Misc

Miscellaneous:
1:1 Switch=Not connected
This screen displays the following information:
Display
Top line
Bottom line
Front Panel Operation
Normal
Item
Operational Mode
1:1 Switch Link Status
Redundancy Status
CDM-425 Advanced Satellite Modem
Address= 0000
9600 baud
Terr REF TxClk
EbNo LNB
Online
Configuration Setting
Test Mode or Normal.
Connected or Not Connected.
Offline or Online.
6–92
Revision 0
8N1
BUC
CEX
MN-CDM-425
