7.2.1 Management Information Base (MIB) Files

MIB files are used for SNMP remote management of a unique device. A MIB file consists of a tree
of nodes called Object Identifiers (OIDs). Each OID provides remote management of a particular
function. These MIB files should be compiled in a user-supplied MIB Browser or SNMP Network
Monitoring System server. The following MIB files are associated with the CDM-570A/570AL:
MIB File/Name
(where 'x' is revision letter)
FW10874-2x.mib
ComtechEFData MIB file
FW-0020760x.mib
CDM-570A MIB file
-or-
FW-0020761x.mib
CDM/R-570AL MIB file
FW-0020786x.mib
CDM-570A/570AL Packet
Processor MIB file
FW-0020762x.mib
CDM-570A Traps MIB file
-or-
FW-0020763x.mib
CDM/R-570AL Traps MIB file
FW10874-6x.mib
CDM/R-570AL BUC/LNB MIB file
FW10874-7x.mib
CDM/R-570AL BUC/LNB Traps
MIB file
FW10874-8x.mib
CSAT-5060 MIB file
FW10874-9x.mib
KST-2000A/B MIB file

7.2.2 SNMP Community Strings

CAUTION – In SNMP v1/v2c, the SNMP Community String is sent unencrypted in
the SNMP packets. Caution must be taken by the network administrator to
ensure that SNMP packets travel only over a secure and private network if
security is a concern.
The CDM-570A/570AL uses Community Strings as a password scheme that provides
authentication before gaining access to the CDM-570A/570AL Agent MIBs. They are used to
authenticate users and determine access privileges to the SNMP Agent.
Ethernet-based Remote Product Management
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Description
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data products
and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path:
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
MIB file consists of all of the OIDs for management of the CDM-570A/570AL
modem functions
MIB file consists of all of the OIDs for management of the CDM-570A/570AL
optional Packet Processor functions
Trap MIB file is provided for SNMPv1 traps common for base modems.
L-Band unit MIB file consists of all of the OIDs for management of the BUC and
LNB.
L-Band unit Trap MIB file is provided for BUC and LNB SNMPv1 traps
MIB file consists of all the OIDs for management of the CSAT-5060 Transceiver
connected to the CDM-570A modem through FSK.
MIB file consists of all the OIDs for management of the KST-2000A/B
Transceiver connected to the CDM-570A modem through FSK.
