Start of
Packet
<
ASCII code 60
(1 character) (4 characters)
Example: <0135/TFQ=70.2345{CR}
Start of
Packet
>
ASCII code 62
(1 character) (4 characters)
Example: >0654/RSW=32{CR}{LF}
ODU (Transceiver, BUC, LNB) Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Controller-to-Target
Target Address
Address Delimiter
/
ASCII code 47
(1 character)
Target-to-Controller
Target Address
Address Delimiter
/
ASCII code 47
(1 character)
Instruction Code
Code Qualifier
= or ?
ASCII codes
61 or 63
(3 characters)
(1 character)
Instruction Code
Code Qualifier
=, ?, !, or *
ASCII codes
61, 63, 33, or
42
(3 characters)
(1 character)
10–4
Revision 5
Optional
End of Packet
Arguments
Carriage
Return
ASCII code 13
(n characters)
(1 character)
Optional End of
Arguments Packet
Carriage
Return, Line
Feed
ASCII codes
(From 0 to n
13,10
characters)
(2 characters)
