10.3.1.1

S ELECT: (Main) Menu

5 B 5 B
SELECT: Config
Test Info Save/Load Util
The table that follows identifies the commands comprising the CDM/R-570AL main menu, and the
content section in this manual where explicit information may be referenced, either in this chapter
or in Chapter 6. FRONT PANEL OPERATION:
Menu Branch
Config
Monitor
Test
Info
Save/Load
Util
For ODU operation, use the ◄ ► arrow keys to select Config or Monitor, and then press
ENTER.
10.3.1.1.1

(SELECT:) Config (Configuration)

CONFIG: Rem All Tx Rx CEx
Frame TI Ref Msk CnC ODU
For ODU operations, use the ◄ ► arrow keys to select Msk or ODU, and then press ENTER.
10.3.1.1.1.1

CONFIG: Msk (Alarm Masking)

Alarm Mask: Transmit
Receive Ref BUC LNB (◄►)
For ODU operations, use the ◄ ► arrow keys to select BUC or LNB, and then press ENTER.
10.3.1.1.1.2

(CONFIG: Alarm Mask) BUC

BUC Alarm:
Active Masked (◄ ►,ENT)
Use the ◄ ► arrow keys to select Active or Masked, and then press ENTER. By selecting
Masked, no alarm will be generated.
ODU (Transceiver, BUC, LNB) Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Monitor
Chapter
Function
Sect.
6.3.2,
Use to fully configure the modem and the ODU.
10.3.3.1
6.3.3, Used to monitor the alarm status of the modem and the ODU, to view the log of
10.3.1.3 stored events, and to display the Receive Parameters screen.
6.3.4 Used to invoke one of several test modes (loopbacks, for example).
(Information) Used to view information on the modem, without having to go into
6.3.5
configuration screens.
Used to save (store) and to load (retrieve) up to 10 different modem
6.3.6
configurations.
(Utility) Used to perform miscellaneous functions, such as setting the real-time
6.3.7
clock, adjusting the display brightness, etc.
