7.2.1 Management Information Base (MIB) Files

MIB files are used for SNMP remote management of a unique device. A MIB file consists of a
tree of nodes called Object Identifiers (OIDs). Each OID provides remote management of a
particular function. These MIB files should be compiled in a user-supplied MIB Browser or SNMP
Network Monitoring System server. The following MIB files are associated with the
CDM-570A/570AL:
MIB File/Name
(where 'x' is revision letter)
FW10874-2x.mib
ComtechEFData MIB file
FW-0020760x.mib
CDM-570A MIB file
-or-
FW-0020761x.mib
CDM/R-570AL MIB file
FW-0020786x.mib
CDM-570A/570AL Packet
Processor MIB file
FW-0020762x.mib
CDM-570A Traps MIB file
-or-
FW-0020763x.mib
CDM/R-570AL Traps MIB file
FW10874-6x.mib
CDM/R-570AL BUC/LNB MIB file
FW10874-7x.mib
CDM/R-570AL BUC/LNB Traps
MIB file
FW10874-8x.mib
CSAT-5060 MIB file
FW10874-9x.mib
KST-2000A/B MIB file

7.2.2 SNMP Community Strings

CAUTION – In SNMP v1/v2c, the SNMP Community String is sent unencrypted in the
SNMP packets. Caution must be taken by the network administrator to ensure that
SNMP packets travel only over a secure and private network if security is a concern.
The CDM-570A/570AL uses Community Strings as a password scheme that provides
authentication before gaining access to the CDM-570A/570AL Agent MIBs. They are used to
authenticate users and determine access privileges to the SNMP Agent.
Description
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data products
and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path:
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
MIB file consists of all of the OIDs for management of the CDM-570A/570AL
modem functions
MIB file consists of all of the OIDs for management of the CDM-570A/570AL
optional Packet Processor functions
Trap MIB file is provided for SNMPv1 traps common for base modems.
L-Band unit MIB file consists of all of the OIDs for management of the BUC and
LNB.
L-Band unit Trap MIB file is provided for BUC and LNB SNMPv1 traps
MIB file consists of all the OIDs for management of the CSAT-5060 Transceiver
connected to the CDM-570A modem through FSK.
MIB file consists of all the OIDs for management of the KST-2000A/B
Transceiver connected to the CDM-570A modem through FSK.
