Radius M&C Using Telnet - Comtech EF Data CDM-570A Installation And Operation Manual

•
RADIUS Client – Use the drop-down list to set RADIUS operation as Enabled or Disabled.
•
Server Password Type – Use the drop-down list to select the authentication protocol as
PAP (Password Authentication Protocol) or CHAP (Challenge-Handshake Authentication
Protocol).
•
Primary / Secondary Server IP Address – Enter the pertinent Server IP Addresses in the
form xxx.xxx.xxx.xxx.
•
Server Shared Secret – Carefully enter the word to be used (64 characters maximum) as
the "shared secret" between the RADIUS Client Server and the networked device (CDM-
570A/570AL). The interface conceals this entry for security purposes.
•
Server Port – Enter a valid port number from 1 to 65535 (the default is 1812).
Click [Submit Radius] to save.
•
RADIUS Log – This scrollable window displays the last 20 users who have logged onto the
RADIUS server.
I.4.2 RADIUS M&C Using Telnet
• Chapter 7. ETHERNET-BASED REMOTE PRODUCT MANAGEMENT
•
Chapter 8. SERIAL-BASED REMOTE PRODUCT MANAGEMENT
The RADIUS commands/queries are available only if you log in to the Telnet
Remote Control Interface (not to be confused with the Telnet CLI – Command Line
Interface) using the Administrator Name and Password.
Command/Query
RAE
RAA
RAB
RAP
RAT
RAS
RADIUS Client
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Enables/Disables RADIUS operation
Assigns the Primary RADIUS Client Server IP Address
Assigns the Secondary RADIUS Client Server IP Address
Assigns the RADIUS Server Port Address
Defines the RADIUS Client Server password authentication protocol
Assigns the RADIUS Client Server shared secret
I–6
Function
Revision 5
MN-CDM570A
