8.2

SNMP Interface

The SNMP is an Internet-standard protocol for managing devices on IP networks. An SNMP-
managed network consists of three key components:
•
The managed device. This includes the SLM-5650A Satellite Modem.
•
The SNMP Agent. The software that runs on the SLM-5650A. The SLM-5650A SNMP
Agent supports SNMPv1, SNMPv2c, and SNMPv3.
•
The user-supplied NMS. The software that runs on the manager.
8.2.1

Management Information Base (MIB) Files

MIB files are used for SNMP remote management of a unique device. A MIB file consists of a tree
of nodes called Object Identifiers (OIDs). Each OID provides remote management of a particular
function. These MIB files should be compiled in a user-supplied MIB Browser or SNMP Network
Monitoring System server.
The following MIB files are associated with the SLM-5650A:
MIB File/Name
( 'x' indicates revision letter)
fw10874-2x.mib
ComtechEFData MIB file
FW-0000049x.mib
SLM-5650A OID MIB File
FW-0000050x.mib
SLM-5650A Traps MIB file
Ethernet Interface Operation
Description
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data products
and consists of only the following OID:
Name: ComtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path:
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
MIB file consists of all of the OID's for management of the modem functions.
Trap MIB file is provided for SNMPv1 traps common for base modems.
