D.2.6.1 Configure User PCs
Do these steps:
Step Task
1 For User PC 1:
• Set the IP Address to 172.17.10.11;
• Set the mask to 255.255.255.0;
• Set the PC Gateway IP Address to 172.17.10.1.
2 For User PC 2:
• Set the IP Address to 172.16.10.11;
• Set the mask to 255.255.255.0;
• Set the PC Gateway IP Address to 172.16.10.1.
3 Reboot the PCs (if required).
D.2.6.2 Set CDM-IP Modems to Router Mode Operation
Do these steps on CDM-IP 1 (the applicable CLI "hot key" is shown in brackets [#]):
Step Task
1 From the CLI Main Menu:
Select the Administration [A] submenu.
2 From the Administration menu:
Select CDM-IP Working Mode [C].
3
When the following prompt is displayed:
Changing Modem working mode requires system Reboot.
Do you want to continue(Y/N)[Enter :No]
Confirm when prompted by typing 'y'.
•
Select [3] Router-Point to Point for IP SW version 1.6.x or earlier .
•
Select [4] Router-Point to Point for IP SW version 1.7.x or later.
•
4
Allow CDM-IP to reboot.
Both CDM-IP modems are now in Router-Point to Point Mode, which means that the CDM-IP
modems will be on independent IP subnets and will require adding static routes to pass traffic
between them.
