1. Minimum and maximum bandwidth is only configurable for each of the four
Assured Forwarding classes.
2. Typically, DiffServ is implemented using exclusively Class Selector DSCP or
exclusively Expedited and Assured Forwarding DSCP. The IP Packet
Processor is fully DiffServ compliant and will work with either DiffServ
implementation, or with a combination of both.
WRED – The QoS system supports WRED-based congestion avoidance. WRED can be enable
or disabled on any queue. When WRED is disabled, upon overdriving the queue the packets will
be tail dropped.
L.1.3.1 DiffServ QoS Mode Example
Do these steps:
1. Select DiffServ QoS mode.
2. Set the modem Tx bandwidth to 10 Mbps.
The input streams to the modem are as follows:
Stream
Management
Networking
Control
Voice
Video
Data-1
Data-2
Data-3
Data-4
Data-5
Data-6
Data-7
Advanced Quality of Service (QoS) Option
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Priority PHB / DSCP Code
1 CS7 / b111000
2 CS6 / b110000
3 EXFD / b101110
3 CS5 / b101000
4 CS4 / b100000
5 CS3 / b011000
7 ASFD4 / b100010
7 ASFD3 / b011010
7 ASFD2 / b010010
7 ASFD1 / b001010
8 BE / bXXXXXX
L–9
Service
Drop Precedence
Rate
NA NA
NA NA
NA NA
NA NA
NA NA
NA NA
100 low
400 low
500 low
800 low
NA NA
Revision 5
Data Rate
200 Kbps
800 Kbps
1Mbps
4 Mbps
550 Kbps
1450 Kbps
1 Mbps
1 Mbps
1 Mbps
1 Mbps
2 Mbps
