6.3.5.3
INFO: Rx (Receive)
Rx:1140.000 5000.000 TUR
8P 0.95 D BUF +/-32k
This screen displays Receive information as follows:
Display Line
Top Line
(from left)
Bottom Line
(from left)
6.3.5.4
INFO: Buf (Buffer)
Buffer: Enabled
Size:+/-04096 bits (ENT)
This screen reports if the buffer is Enabled or Disabled; shows the exact clocking mode (Tx=Rx, or
Tx< > Rx); and displays the buffer size.
6.3.5.5
INFO: Frame (Framing and EDMAC)
This screen displays the framing mode and whether the modem is EDMAC Master or Slave, with
the appropriate address. Examples are as follows:
Framing: Disabled
(ENTER or CLEAR)
Framing: AUPC-Only,EDMAC2
(ENTER or CLEAR)
Framing: AUPC+EDMAC2
Master,0240 (ENT or CLR)
Framing: AUPC+EDMAC
Slave, 0241 (ENT or CLR)
Front Panel Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
I
Description
• Receive Frequency and Data Rate (NOTE: Due to space limitations, the resolution of
displayed frequency is limited to 1 kHz, and data rate to 10Hz,)
• FEC Decoder type (VIT = Viterbi, VRS=Viterbi + Reed-Solomon, TCM = Trellis Coded +
Reed-Solomon, TUR = TPC, VFEC = VersaFEC, VersaFEC-2 (Long) = VF2L,
VersaFEC-2 (Short) = VF2S, ULL = Ultra Low Latency, UNC = uncoded)
• Demodulation type (Q = QPSK, OQ= OQPSK, B = BPSK, 8P = 8-PSK, 8Q = 8QAM,
16=16-QAM, 8-ARY, 16-ARY, 32-ARY).
• Code Rate (Unc = Uncoded, 2144 = 21/44, then 5/16, 1/2, 2/3, 3/4, 7/8, 0.95)
• Descrambler state (D = Descrambler on, N = Descrambler off, I = IESS-315 On)
• Clocking Mode (SAT = buffer disabled, BUF = buffer enabled, CXE = internal & Clock
Extend RxEnable E1 mode, CXT = internal & Clock Extend RxEnable T1 mode)
• Demod Sweep Acquisition range
• RSI state (I = Receive Spectral Inversion on, N = off)
(Tx=Rx)
6–60
Revision 5
MN-CDM570A
