(ODU CONFIG ► ODU RX:) Mute
ODU Rx Mute State:
Muted
Use the ◄ ► arrow keys to select Muted or Unmuted, and then press ENTER.
(ODU CONFIG ► ODU RX:) Slope
ODU Rx Slope Mode:
Manual
Use the ◄ ► arrow keys select Manual or Calibrated, and then press ENTER.
(ODU CONFIG ► ODU RX:) Slope ► Manual
ODU Rx Slope:
0.0
Use the ▲▼arrow keys to edit the ODU Rx Slope setting, and then press ENTER.
(ODU CONFIG ► ODU RX:) Slope ► Calibrated
Calibrate RX Slope?
Cal
Use the ◄ ► arrow keys to select Cal or Exit, and then press ENTER.
(ODU CONFIG): Misc
MISC: Cold-Start AFR LNA
XRef Ref-Adjust RTC (◄ ►)
Use the ◄ ► arrow keys to select Cold-Start, AFR, LNA, XRef, Ref-Adjust, or RTC, and
then press ENTER.
(ODU CONFIG ► MISC:) Cold-Start
Cold-Start State:
Enabled
Use the ◄ ► arrow keys to select Enabled or Disabled, and then press ENTER.
(ODU CONFIG ► MISC:) AFR (Auto Fault Recovery)
Auto Fault Recovery:
Enabled
Use the ◄ ► arrow keys to select Enabled or Disabled, and then press ENTER.
ODU (Transceiver, BUC, LNB) Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Unmuted (◄ ►,ENT)
Calibrated (◄ ►)
▲ ▼,
( ENT)
Exit (◄ ►,ENT)
Disabled (◄ ►)
Disabled (◄ ►)
