M&C is accomplished as follows:
•
Selection – This is the function or command as it appears on the menu page.
•
Hot Key – This is the letter or number assigned as the keystroke/mnemonic for execution
of a menu function or command. Where this column specifies [RO], this means that this
line item is a read-only (informational) feature. No user input is available.
•
Description – This is the detailed explanation of the function or command. You are
instructed to take a specific action here:
When you are instructed to "set" a feature, this means that you are prompted to type
o
the numerical value for that feature. Press [Enter] to execute configuration. User
guidance to "set" a value within a permitted ranges (from a minimum value to a
maximum value) is commonly provided in parentheses or brackets.
When you are instructed to "select" a feature, this means that a numbered list of
o
choices is commonly provided. Type the number to execute your operational
selection. Press [Enter] to execute configuration.
When you are instructed to "toggle" a feature, this generally means that pressing the
o
Hot Key executes one of two operating states for that feature (e.g., Enabled or
Disabled, On or Off, Auto or Manual, etc.). The feature line will dynamically update to
display, in brackets, its updated and current operating state.
D.2.4 Restoring Factory Default Configuration
The configuration procedures provided in this chapter assume that the CDM-IP is still in factory
default configuration for IP. If this is not the case, the factory default configuration can be restored
from the CLI menu.
Do these steps (the applicable CLI "hot key" is shown in brackets [#]):
Step Task
1 From the CLI Main Menu:
Select Operations and Maintenance submenu [O].
2 From the Operations and Maintenance menu:
Select Database Operations submenu [D].
3 From the Database Operations menu:
Select Restore Factory Default option [R].
4 The following prompt appears:
Are you sure you want to restore factory default settings?
WARNING: Choosing Yes will restore factory defaults and then
reboot..
Type 'y' to confirm. This erases user configurations and restores CDM-IP factory default configuration.
Proceed either to Sec. D.2.5 to perform the Managed Switch Mode configuration, or to Sect. D.2.6 to
5
perform the Router Mode configuration.
D.2.5

Configuring a Managed Switch Point-to-Point System

The procedures outlined in this section result in the configuration shown in Figure D-3.
