BERT Config
Use the drop-down lists provided in this section to configure BERT for Tx or Rx as On or Off;
configure the pattern for Tx or Rx; and set Error Insertion as either Off or 10E-3.
Click [Submit BERT] once you select the desired BERT settings.
Use of this feature is UNAVAILABLE when operating in CDM-570 Compatibility
Mode. See Sect. 7.4.3.3.8 for further information.
BERT Monitor
This read-only section displays the ongoing BERT. Click [Restart] to restart the BERT Monitor,
or [Update] to refresh a test already in progress.
Use of this feature is UNAVAILABLE when operating in CDM-570 Compatibility
Mode. See Sect. 7.4.3.3.8 for further information.
Save / Load (Save takes precedence over Load)
As a safeguard, to prevent any inadvertent action the Save Location and Load Location drop-
down lists' default selections are Don't Save and Don't Load, respectively. Otherwise:
•
Save Location / Load Location – Use the drop-down lists to save or load up to 10
different modem configurations – 0 through 9. An empty location is noted on its menu line
as Available.
Click [Submit Save/Load] to save.
7.4.3.3.8.1

Configuration | Utilities | Carrier ID (MetaCarrier)

It is IMPORTANT to understand that Carrier ID is a distinct feature of the
CDM-570A/570AL. Read your documentation carefully.
Note that in accordance with the DVB specifications, Carrier ID is only
available when the Transmit symbol rate is greater than, or equal to
128 ksps.
Appendix R. CARRIER ID (MetaCarrier)
Ethernet-based Remote Product Management
CDM-570A/570AL Satellite Modem with Optional Packet Processor
