CDM-710/L Broadcast Satellite Modem
Ethernet Interface Operation
• The unit is operating with the latest version firmware files.
• The User PC is running a terminal emulation program for operation of the
unit Telnet Interface.
• The User PC is running a compatible web browser for operation of the
unit HTTP Interface.
• The User PC is connected to the CDM-710/L's RJ-45 'J4 | Ethernet' port.
• You have recorded the unit's Management IP Address.

8.2 SNMP Interface

SNMP is an Internet-standard protocol for managing devices over IP networks. An
SNMP-managed network has three key components:
• The managed device. This includes the CDM-710/L.
• The SNMP Agent. This software runs on the unit. The unit SNMP Agent
supports both SNMPv1 and SNMPv2c.
• The user-supplied Network Management System (NMS). This software
runs on the User PC.

8.2.1 Management Information Base (MIB) Files

An MIB file is used for SNMP remote management of a unique device, and
consist of a tree of nodes called Object Identifiers (OIDs). Each OID provides
remote management of a particular function. These MIB files should be compiled
in a user-supplied MIB Browser or SNMP Network Monitoring System server. In
these modem MIB file names, the letter 'x' represents the revision of the file.

8.2.1.1 ComtechEFData Root MIB File

• Fw10874-2x.mib
• ComtechEFData MIB file gives the root tree for all Comtech EF Data
modem products and consists of only the following OID:
o Name: comtechEFData
o Type: MODULE-IDENTITY
o OID: 1.3.6.1.4.1.6247
o Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).
comtechEFData(6247)
o Module: ComtechEFData
8–2
MN/CDM710.IOM
Revision 12
