Command Arguments for
Parameter (Instruction
Type Code and
Qualifier)
Remote Eb/No N/A 4 bytes
Tx Power Level N/A 3 bytes
Increase
Tx Clock Source TCK= 1 byte,
value of 0, 1, or 2
Tx Clock Invert TCI= 1 byte,
value 0 or 1
Terminal Tx N/A 10 bytes
Frequency
Serial-based Remote Product Management
Command or
Response to
Query
Query only.
Returns the value of Eb/No of the remote demod in the form xx.x, where:
xx.x = 02.0 to 16.0
Response is 99.9 if remote demod unlocked.
Response is xx.x if EDMAC is disabled.
Example: <0/REB?
>0/REB=12.4
Note: For values >16.0 dB, the response = 16.0
Query only.
Returns the increase in Tx power level, in dB (from the nominal setting) due to the action
of AUPC.
Range is 0.0 to 9.9 dB
Example: <0/PLI?
>0/PLI=2.3
Note: Response is ds x.x if AUPC is disabled.
Command or Query.
Sets or returns Tx Clock Source in the form x, where:
0 = Internal
1 = Tx Terrestrial
2 = Loop-Timed
Note: When TCK is changed from Internal to Non-Internal, Clock Extension Mode
automatically changes to 0=None if it was 1=TxLock. Reply: TCK+
Example: <0/TCK=0 (selects Internal)
Command or Query.
Sets or returns Invert Transmit Data Clock in the form x, where:
0 = Normal
1 = Invert
Query only – CDM/R-570AL only.
Returns Terminal Tx Frequency in the form xxxxx.xxxx , where:
xxxxx.xxxx = frequency (BUC LO ± TFQ)
Resolution = 100 Hz
Returns 00000.0000 if LNB LO is zero
Example: <0/TTF?
>0/TTF=14250.9872
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Description of Arguments
8–17
Revision 5
Query
Response to
(Instruction Code
Command
and Qualifier)
N/A REB? REB=xx.x
(see Description of
Arguments)
N/A PLI? PLI=x.x
(see Description of
Arguments)
TCK= TCK? TCK=x
TCK? (see Description of
TCK* Arguments)
TCK#
TCI= TCI? TCI=x
TCI? (see Description of
TCI* Arguments)
TCI#
N/A TTF? TTF=xxxxx.xxxx
(see Description of
Arguments)
MN-CDM570A
Response to
Query
