Example: In the above diagram, the (Co+No)/No measured is 4.6 dB. If Rate 1/2 QPSK is being
used, this would correspond to an E
The exact relationship used to derive the table values is as follows:
E /N = 10 log
b 0 10
Where:
•
E /N and (Co+No)/No are expressed in dB
b 0
•
Bits/symbol = 1 for BPSK
•
Bits/symbol = 2 for QPSK
•
Bits/symbol = 3 for 8-PSK/8-QAM
•
Bits/symbol = 4 for 16-QAM
•
Code Rate for 'uncoded' = 1
Pay close attention to the sign of the middle term.
